Goodrive35 Series Closed-loop Vector Control VFD
Bit
8 WIRTE ENABLE
9–10 MOTOR GROUP SELECTION
TORQUE CONTROL
11
SELECTION
ELECTRIC CONSUMPTION
12
13 PRE-EXCIATION
14 DC BRAKE
15 HEARTBEAT REF
Reference value (REF): From 2
frequency set value is offered by main setting signal source. As PWM rectifier feedback part doesn't
have main frequency setting part, corresponding settings belong to reserved part, the following table
shows inverter part settings for Goodrive35.
Bit
PZD2 receiving
PZD3 receiving
PZD4 receiving
PZD5 receiving
PZD6 receiving
PZD7 receiving
PZD8 receiving
PZD9 receiving
PZD10 receiving
PZD11 receiving
PZD12 receiving
Name
CLEAR
nd
word to 12
0: Invalid
1: Set frequency (0–Fmax (unit: 0.01 Hz))
2: Given PID, range (0–1000, 1000 corresponds to
100.0%)
3: PID feedback, range (0–1000, 1000 corresponds to
100.0%)
4: Torque set value (-3000–3000,1000 corresponds to
100.0% the rated current of the motor)
5: Set value of the forward rotation upper-limit
frequency (0–Fmax unit: 0.01 Hz))
6: Set value of the reversed rotation upper-limit
frequency (0–Fmax (unit: 0.01 Hz))
7: Electromotion torque upper limit (0–3000,1000
Value
6 Coast to stop (Emergency stop)
7 Fault reset
8 Jogging stop
1 Write enable (mainly is PKW1-PKW4 )
00 MOTOR GROUP 1 SELECTION
01 MOTOR GROUP 2 SELECTION
02 MOTOR GROUP 3 SELECTION
03 MOTOR GROUP 4 SELECTION
1 Torque control enable
0 Torque control disable
1 Electric consumption clear enable
0 Electric consumption clear disable
1 Pre-excitation enable
0 Pre-excitation disable
1 DC brake enable
0 DC brake disable
1 Heartbeat enable
0 Heartbeat disable
th
of PZD task message is the main set value REF, main
Name
248
State/Description
Function selection
Extension card
0
0
0
0
0
0
0
0
0
0
0
