Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Communication
P00.02
running commands
Max. output
P00.03
frequency
Upper limit of the
P00.04
running frequency
Lower limit of the
P00.05
running frequency
Detailed instruction of parameters
Set the multi-function key QUICK/JOG to FWD/REV
shifting function (P07.02=3) to change the running
direction; press
simultaneously in running state to make the VFD
coast to stop.
1: Terminal running
("LOCAL/REMOT" flickering)
Carry out the running command control by the
forward rotation, reverse rotation and forward
jogging and reverse jogging of the multi-function
terminals
2: Communication running command channel
("LOCAL/REMOT" on);
The running command is controlled by the upper
monitor via communication
Select the controlling communication command
channel of the VFD.
0: Modbus communication channel
1: PROFIBUS\CANopen communication channel
2: Ethernet communication channel
3: Reserved
Note: 1, 2 and 3 are extension functions which need
corresponding extension cards.
This parameter is used to set the maximum output
frequency of the VFD. Users should pay attention to
this parameter because it is the foundation of the
frequency setting and the speed of acceleration and
deceleration.
Setting range: P00.04–400.00 Hz
The upper limit of the running frequency is the upper
limit of the output frequency of the VFD which is
lower than or equal to the maximum frequency.
Setting range: P00.05–P00.03
frequency)
The lower limit of the running frequency is that of the
output frequency of the VFD.
The VFD runs at the lower limit frequency if the set
frequency is lower than the lower limit one.
47
RUN and STOP/RST
command
(max.
Function parameters
Default Modif
value
channel
0
50.00
Hz
50.00
Hz
output
0.00 Hz
y
○
◎
◎
◎
