Goodrive35 Series Closed-loop Vector Control VFD
Function
code
Rotor resistor of asynchronous
P12.07
Leakage inductance of
P12.08
asynchronous motor 2
Mutual inductance of
P12.09
asynchronous motor 2
P12.10
asynchronous motor 2
Rated power of synchronous
P12.15
Rated frequency of synchronous
P12.16
Number of poles pairs for
P12.17
synchronous motor 2
Rated voltage of synchronous
P12.18
Rated current of synchronous
P12.19
Stator resistor of synchronous
P12.20
Direct axis inductance of
P12.21
synchronous motor 2
Quadrature axis inductance of
P12.22
synchronous motor 2
Back EMF constant of
P12.23
synchronous motor 2

7.7 Start-up and stop control

The start-up and stop control of the VFD includes three states: start after the running command during
normal powering on, start after the restarting function becomes valid during normal powering on and
start after the automatic fault reset.
There are three starting modes for the VFD: start from the starting frequency directly, start after the
AC brake and start after the rotation speed tracking. The user can select according to different
situations to meet their needs.
For the load with big inertia, especially in the cases where the reverse rotation may occur, it is better
to select starting after DC brake and then starting after rotation speed tracking.
Note: It is recommended to use the direct starting to drive synchronous motor.
Name
motor 2
Non-load current of
motor 2
motor 2
motor 2
motor 2
motor 2
Detailed instruction of parameters
0.001–65.535 Ω
0.1–6553.5 mH
0.1–6553.5 mH
0.1–6553.5 A
0.1–3000.0 kW
0.01 Hz–P00.03
frequency)
1–128
0–1200 V
0.8–6000.0 A
0.001–65.535 Ω
0.01–655.35 mH
0.01–655.35 mH
0–10000
156
Basic operation instruction
Default
value
Depend on
model
Depend on
model
Depend on
model
Depend on
model
Depend on
model
(max. output
50.00 Hz
Depend on
model
Depend on
model
Depend on
model
Depend on
model
Depend on
model
2
300
