Note: Some parameters in the preceding table are valid only after they are enabled. Take the running
and stop operations as examples, you need to set "Running command channel" (P00.01) to
"Communication", and set "Communication running command channel" (P00.02) to the Modbus
communication channel. For another example, when modifying "PID setting", you need to set "PID
reference source" (P09.00) to Modbus communication.
The following table describes the encoding rules of device codes (corresponding to the identification
code 2103H of the VFD).
MSB of the code
01

10.4.6 Fieldbus ratio values

In practical applications, communication data is represented in the hexadecimal form, but
hexadecimal values cannot represent decimals. For example, 50.12 Hz cannot be represented in the
hexadecimal form. In such cases, we can multiply 50.12 by 100 to obtain an integer 5012, and then
50.12 can be represented as 1394H (5012 in the decimal form) in the hexadecimal form.
In the process of multiplying a non-integer by a multiple to obtain an integer, the multiple is referred to
as a fieldbus scale.
The fieldbus scale depends on the number of decimals in the value specified in "Detailed parameter
description" or "Default value". If there are n decimals in the value, the fieldbus scale m is the
th
n -power of 10. Take the following table as an example, m is 10.
Function
code
Hibernation restore
P01.20
Restart after power
P01.21
The value specified in "Detailed parameter description" or "Default value" contains one decimal, so
the fieldbus scale is 10. If the value received by the upper computer is 50, the value of
"Wake-up-from-sleep delay" of the VFD is 5.0 (5.0=50/10).
To set the "Wake-up-from-sleep delay" to 5.0s through Modbus communication, you need first to
multiply 5.0 by 10 according to the scale to obtain an integer 50, that is, 32H in the hexadecimal form,
and then transmit the following write command:
01
VFD
address
Meaning LSB of the code
GD
Name Detailed parameter description
0.0–3600.0s (valid when P01.19 is
2)
delay time
0: Restart is disabled
off 1: Restart is enabled
06 01 14 00 32
Parameter
Write
command address
0x08
0x09
0x0a
Parameter
data
230
Communication protocol
Meaning
GD35 vector VFD
GD35-H1 vector VFD
GD300 vector VFD
Default
value
0.0s
0
49 E7
CRC check
Modify
○
○
