INVT Goodrive35 Series Operation Manual page 121

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Fault time of
P14.04 communication
overtime
Transmission fault
P14.05
processing
Communication
P14.06
processing
Detailed instruction of parameters
is shorter than the system processing time, then the
answer delay time is the system processing time, if
the answer delay is longer than the system
processing time, then after the system deal with the
data, waits until achieving the answer delay time to
send the data to the upper monitor
0.0 (invalid), 0.1–60.0 s
When the function code is set as 0.0, the
communication overtime parameter is invalid
When the function code is set as non-zero, if the
interval time between two communications exceeds
the communication overtime, the system will report
"485 communication faults" (CE).
Generally, set it as invalid; set the parameter in the
continuous communication
communication state.
0: Alarm and stop freely
1: No alarm and continue to run
2: No alarm and stop according to the stop mode
(only under the communication control)
3: No alarm and stop according to the stop mode
(under all control modes)
0x000–0x111
LED ones:
0: Write with response: the VFD will respond to all
reading and writing commands of the upper monitor.
1: Write without response: the VFD only responds to
the reading command rather than the writing
command of the
communication efficiency.
LED tens:
0: Communication encrypting invalid
1: Communication encrypting valid
LED hundreds:
0: Function code
communication are stored during Poff;
1: Function codes are stored based on the MSB of
communication address (1 or 0), which means the
function codes will be stored during Pof if the MSB is
1 or stored immediately if the MSB is 0.
114
to monitor
drive, thus improving
parameters changed
Function parameters
Default Modif
value y
0.0 s ○
the
0
○
0x000
○
by
