Goodrive35 Series Closed-loop Vector Control VFD
Installation guide
Figure 4-11 Terminals of main circuit for the VFDs of 380 V 7.5–11 kW
(+) P B (- ) R
S
T
U
V
W
A1 A2
Figure 4-12 Terminals of main circuit for the VFDs of 380 V 15–18 kW
Figure 4-13 Terminals of main circuit for the VFDs of 380 V 22–30 kW
23
