When select multi-function terminal UP (10) and DOWN (11) to set the internal assistant frequency,
P08.44 and P08.45 can be set to increase or decrease the set frequency quickly.
Up terminal function
selection=10
DOWN terminal function
selection=11
Relative parameters list:
Function
code
P00.03 Max. output frequency
Upper limit of the running
P00.04
Lower limit of the running
P00.05
P00.06 A frequency command
P00.07 B frequency command
B frequency command
P00.08
Combination of the setting
P00.09
F
Sx
Sy
Name
P00.04–400.00 Hz
P00.05–P00.03
frequency
0.00 Hz–P00.04
frequency
0: Keypad
1: AI1
2: AI2
3: AI3
4: High-speed pulse HDI setting
5: Simple PLC program setting
6: Multi-step speed running setting
7: PID control setting
8: Modbus communication setting
9:
setting
10: Ethernet communication setting
11: Reserved
12: Pulse string AB setting
0: Maximum output frequency
reference 1: A frequency command
0: A
1: B
source
2: (A+B) combination
UP terminal frequency increasing integral rate P08.45
DOWN terminal frequency increasing integral rate P08.46
Detailed instruction of parameters
PROFIBUS/CANopen
162
Basic operation instruction
T
UP terminal state
T
DOWN terminal state
T
Default
value
50.00 Hz
50.00 Hz
0.00 Hz
communication
0
2
0
0
