Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
P07.20 Rated VFD current 0.1–6000.0A
P07.21 Factory barcode 1 0x0000–0xFFFF
P07.22 Factory barcode 2 0x0000–0xFFFF
P07.23 Factory barcode 3 0x0000–0xFFFF
P07.24 Factory barcode 4 0x0000–0xFFFF
P07.25 Factory barcode 5 0x0000–0xFFFF
P07.26 Factory barcode 6 0x0000–0xFFFF
P07.27 Current fault type
P07.28 Type of the last fault
Type of the last but
P07.29
one fault
Type of the last but
P07.30
two fault
Detailed instruction of parameters
0: No fault
1: Inverter unit phase protection (OUt1)
2: Inverter unit V phase protection (OUt2)
3: Inverter unit W phase protection (OUt3)
4: ACC overcurrent (OC1)
5: DEC overcurrent (OC2)
6: Constant-speed overcurrent (OC3)
7: ACC overvoltage (OV1)
8: DEC overvoltage (OV2)
9: Constant-speed overvoltage (OV3)
10: Bus undervoltage (UV)
11: Motor overload (OL1)
12: VFD overload (OL2)
13: Input side phase loss (SPI)
14: Output side phase loss (SPO)
15: Overheat of the rectifier module (OH1)
16: Overheat fault of the inverter module (OH2)
17: External fault (EF)
18: 485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotune fault (tE)
21: EEPROM operation fault (EEP)
22: PID response offline fault (PIDE)
23: Brake unit fault (bCE)
24: Running time arrival (END)
25: Electrical overload (OL3)
26: Panel communication fault (PCE)
27: Parameter uploading fault (UPE)
28: Parameter downloading fault (DNE)
87
Function parameters
Default Modif
value y
●
●
●
●
●
●
●
●
●
●
●
