Goodrive35 Series Closed-loop Vector Control VFD
Field identifier
L: General
H: High-performance
Filter application environment
A: Environment Category I, C1 (EN 61800-3:2004)
F
B: Environment Category I, C2 (EN 61800-3:2004)
C: Environment Category II, C3 (EN 61800-3:2004)
D.7.2 Filters for AC 3PH 380 V (-15%)–440 V (+10%)
Model
GD35-1R5G-4-C1/D1/H1
GD35-2R2G-4-C1/D1/H1
GD35-004G-4-C1/D1/H1/H2
GD35-5R5G-4-C1/D1/H1/H2
GD35-7R5G-4- C1/D1/H1/H2
GD35-011G-4- C1/D1/H1/H2
GD35-015G-4-C1/D1/H1/H2
GD35-018G-4-C1/D1/H1/H2
GD35-022G-4-C1/D1/H1/H2
GD35-030G-4-C1/D1/H1/H2
GD35-037G-4-C1/D1/H1
GD35-045G-4-C1/D1/H1
GD35-055G-4-C1/D1/H1
GD35-075G-4-C1/D1/H1
GD35-090G-4-C1/D1/H1
GD35-110G-4-C1/D1/H1
GD35-132G-4-C1/D1/H1
GD35-160G-4-C1/D1/H1
GD35-185G-4-C1/D1/H1
GD35-200G-4-C1/D1/H1
GD35-220G-4-C1/D1/H1
GD35-250G-4-C1/D1/H1
GD35-280G-4-C1/D1/H1
GD35-315G-4-C1/D1/H1
Note:
1. The input EMI meets the C2 requirements after an input filter is configured.
2. The preceding table describes external accessories. You need to specify the ones you choose
when purchasing accessories.
Detailed instruction
Input filter
FLT-P04006L-B
FLT-P04016L-B
FLT-P04032L-B
FLT-P04045L-B
FLT-P04065L-B
FLT-P04100L-B
FLT-P04150L-B
FLT-P04240L-B
FLT-P04400L-B
FLT-P04600L-B
FLT-P04800L-B
283
Optional peripheral accessories
Output filter
FLT-L04006L-B
FLT-L04016L-B
FLT-L04032L-B
FLT-L04045L-B
FLT-L04065L-B
FLT-L04100L-B
FLT-L04150L-B
FLT-L04240L-B
FLT-L04400L-B
FLT-L04600L-B
FLT-L04800L-B
