INVT Goodrive35 Series Operation Manual page 140

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Spindle orientation
P22.01
speed
Spindle orientation
P22.02
DEC time
Spindle zero-point
P22.03
position 0
Spindle zero-point
P22.04
position 1
Spindle zero-point
P22.05
position 2
Spindle zero-point
P22.06
position 3
Spindle indexing
P22.07
angle 1
P22.08 Spindle indexing
Detailed instruction of parameters
is received, the operation mode is automatically
switched to speed control mode.
Bit7: Reference point calibration mode, setting
whether to perform position calibration every time
when the reference point is passed.
0: Calibrated when the reference point is passed for
the first time
1: Calibrated in real time
Bit8: Reserved
Bit9: Positioning completion signal setting
0: Electrical level signal
1: Pulse signal
Bit10: Pulse Z signal source
0: From the motor
1: From the spindle
Bit 11–15: Reserved
Speed for searching for the orientation start position
point. After the orientation start position point is
found, the operation mode is switched to the position
control mode and orientation is performed.
Range: 0.00–100.00 Hz
DEC time in spindle orientation.
It indicates the time the VFD takes to decelerate
from the max. output frequency (P00.03) to 0 Hz.
Setting range: 0.0–100.0s
You can set 4 spindle zero-point positions through
terminals (functions #46 and 47).
Range: 0–39999
Range: 0–39999
Range: 0–39999
Range: 0–39999
You can set 7 spindle indexing angles through
terminals (function #48, 49, and 50).
Range: 0.00–359.99
Range: 0.00–359.99
133
Function parameters
Default Modif
value y
10.00 Hz
○
3.0 s
○
0
○
0
○
0
○
0 ○
15.00
○
30.00
○
