Goodrive35 Series Closed-loop Vector Control VFD
Input motor nameplate
(rotary autotuning)
Note:
1. Set the motor parameters according to the name plate of the motor.
2. During the motor autotune, de-couple the motor form the load if rotation autotune is selected to
make the motor is in a static and empty state, otherwise the result of autotune is incorrect. The
asynchronous motors can autotune the parameters of P02.06–P02.10, while the synchronous motors
can autotune the parameters of P02.20–P02.23.
P00.01=0 (keypad control)
SM
P02.00=1
(P02.12~P02.19)
Set P00.15=1
Press "RUN"key to start
Ready
Motor type
(P02.00)
Set autotuning mode
(P00.15)
Set P00.15=2
(static autotuning 1)
autotuning
In autotuning
Display"-END-"
End
153
Basic operation instruction
AM
P02.00=0
Input motor nameplate
(P02.01~P02.05)
Set P00.15=3
(static autotuning 2)
