Goodrive35 Series Closed-loop Vector Control VFD
Function
code
Simple PLC 0–7 step
P10.34
Simple PLC 8–15 step
P10.35
P10.36
P05.01–P
Digital input function selection
05.09
P06.01–P
Digital output function
06.04
P17.00
Simple PLC and present
P17.27
stage of the multi-step speed

7.14 Multi-step speed running

Set the parameters when the VFD carries out multi-step speed running. Goodrive35 series VFDs can
set 16-stage speed which can be selected by the combination code of multi-step speed terminals 1–4.
They correspond to multi-step speed 0 to 15.
Name
ACC/DEC time
ACC/DEC time
PLC restart
Set frequency
Detailed instruction of parameters
0x0000–0XFFFF
0x0000–0XFFFF
0: Restart from the first stage
1: Continue to run from the stop frequency
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
15: Underload pre-alarm
16: Completion of simple PLC stage
0.00 Hz–P00.03 (max. output frequency)
0–15
183
Basic operation instruction
Default
value
0000
0000
0
0.00 Hz
0
