Goodrive35 Series Closed-loop Vector Control VFD
Figure 4-17 Terminals of main circuit for the VFDs of 380 V 220–315 kW and 660 V 250–350 kW
Figure 4-18 Terminals of main circuit for the VFDs of 660 V 400–630 kW
Terminal
380 V
≤30 kW
R, S, T Power input of the main circuit
U, V, W
P1 /
Brake
(+)
resistor 1
(-) /
Terminal name
380 V ≥37 kW
660 V
The VFD output
DC reactor terminal 1 P1 and (+) are connected with the terminals of DC
DC reactor terminal 2,
brake unit terminal 1
Brake unit terminal 2
3-phase AC input terminals which are generally
connected with the power supply.
3-phase AC output terminals which are generally
connected with the motor.
reactor.
(+) and (-) are connected with the terminals of
brake unit.
