Goodrive35 Series Closed-loop Vector Control VFD
Function
code
Corresponding AO1 output
P06.18
P06.19 Upper output limit of AO1 P06.13–300.0%
Corresponding AO1 output
P06.20
P06.21 AO1 output filter time
P06.22 Lower output limit of AO2 -300.0%–P06.24
Corresponding AO2 output
P06.23
P06.24 Upper output limit of AO2 P06.18–300.0%
The corresponding AO2
P06.25
output of upper limit
P06.26 AO2 output filter time
P06.27 Lower output limit of HDO -300.0%–P06.29
Corresponding HDO
P06.28
output of lower limit
P06.29 Upper output limit of HDO P06.23–300.0%
Corresponding HDO
P06.30
output of upper limit
P06.31 HDO output filter time

7.11 Digital input

Goodrive35 series VFDs have 8 programmable digital input terminals and 1 open circuit electrode
output terminal in the standard configuration. All functions of the digital input terminals are
programmable by the function codes. Open collector pole input can be selected into high speed pulse
input terminal or common switch input terminal by function code. When selected into HDI, the user
can select HDI high speed pulse input as frequency reference, counting input or length pulse input by
setting.
Name
of lower limit
of upper limit
of lower limit
Detailed instruction of parameters
0.00 V–10.00 V
0.00 V–10.00 V
0.000 s–10.000 s
0.00 V–10.00 V
0.00 V–10.00 V
0.000 s–10.000 s
0.00–50.00 kHz
0.00–50.00 kHz
0.000 s–10.000 s
169
Basic operation instruction
Default
value
0.00 V
100.0%
10.00 V
0.000 s
0.0%
0.00 V
100.0%
10.00 V
0.000 s
0.0%
0.0 kHz
100.0%
50.00 kHz
0.000 s
