INVT Goodrive35 Series Operation Manual page 66

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Stator resistor of AM
P02.06
1
Rotor resistor of AM
P02.07
1
Leakage inductance
P02.08
of AM 1
Mutual inductance of
P02.09
AM 1
Non-load current of
P02.10
AM 1
Magnetic saturation
P02.11 coefficient 1 for iron
core of AM1
Magnetic saturation
P02.12 coefficient 2 for iron
core of AM1
Magnetic saturation
P02.13 coefficient 3 for iron
core of AM1
P02.14 Magnetic saturation 0.0–100.0%
Detailed instruction of parameters
0.001–65.535Ω
0.001–65.535Ω
0.1–6553.5mH
0.1–6553.5mH
0.1–6553.5A
0.0–100.0%
0.0–100.0%
0.0–100.0%
59
performance, configure
the motor based on the
motor which matches with
the VFD. If the gap
between motor power and
the matched motor is too
large, the control
performance of the VFD
will be deteriorated
greatly.
Note: P02.02–P02.10
can be initialized
resetting rated
power P02.01.
After motor parameter
autotuning finishes, the
setting value
P02.06–P02.10 will
updated automatically.
These parameters are the
basic parameters
high-performance vector
control, which will impact
the control performance
directly.
Note: Users cannot
change this group
parameters at will.
Function parameters
Default Modif
value y
by
motor
Depend
○
on model
of
Depend
○
be
on model
Depend
○
on model
for
Depend
○
on model
Depend
○
on model
of
80.0%
◎
68.0%
◎
55.0%
◎
40.0%
◎
