INVT Goodrive35 Series Operation Manual page 78

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
motor 2
V/F voltage 3 of
P04.21
motor 2
V/F slip
P04.22 compensation gain
of motor 2
Vibration control factor
P04.23 at low frequency of
motor 2
Vibration control factor
P04.24 at high frequency of
motor 2
Vibration control
P04.25
threshold of motor 2
Energy-saving
P04.26
operation
P04.27 Voltage setting
Keypad setting
P04.28
voltage
Detailed instruction of parameters
In SVPWM control mode, current fluctuation may
occur to the motor on some frequency, especially the
motor with big power. The motor cannot run stably or
overcurrent may occur. These phenomena can be
canceled by adjusting this parameter.
The setting range of P04.23: 0–100
The setting range of P04.24: 0–100
The setting range of P04.25: 0.00 Hz–P00.03 (max.
output frequency)
0: No operation
1: Automatic energy-saving operation (reserved)
Motors will automatically adjust the output voltage to
save energy when light loads.
Select the output setting channel at V/F curve
separation.
0: Keypad: the output voltage is determined by
P04.28.
1: AI1 ;
2: AI2;
3: AI3;
4: HDI;
5: Multi-step speed;
6: PID;
7: Modbus communication;
8: PROFIBUS/CANopen communication;
9: Ethernet communication;
10: Reserved
Note: 100% corresponds to the rated motor voltage.
The function code is the voltage displaying when the
voltage is set through keypad.
The setting range: 0.0%–100.0%
71
Function parameters
Default Modif
value y
0.0%
○
100.0%
○
10
○
10
○
30.00
○
Hz
0
◎
0
○
100.0%
○
