Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
UP terminals
P08.45 frequency changing
ratio
DOWN terminals
P08.46 frequency changing
ratio
Frequency setting at
P08.47
power loss
MSB of initial power
P08.48
consumption
LSB of initial power
P08.49
consumption
P08.50 Magnetic flux brake
Detailed instruction of parameters
0.01–50.00 Hz/s
0.01–50.00 Hz/s
0x000–0x121
LED ones: Action selection when power off.
0: Save when power off
1: Clear when power off
LED tens: Action selection when Modbus set
frequency off
0: Save when power off
1: Clear when power off
2: Clear when stop
LED hundreds: The action selection when other
frequency set frequency off
0: Save when power off
1: Clear when power off
This parameter is used to set the original value of the
power consumption.
The original value of the power consumption
=P08.48*1000+ P08.49
Setting range of P08.48: 0–59999 kWh (k)
Setting range of P08.49: 0.0–999.9 kWh
This function code is used to enable magnetic flux.
0: Invalid.
100–150: The bigger the coefficient, the stronger the
brake is.
This VFD is used to increase the magnetic flux to
decelerate the motor. The energy generated by the
motor during brake can be converted into heat
energy by increasing the magnetic flux.
The VFD monitors the state of the motor
continuously even during the magnetic flux period.
So the magnetic flux can be used in the motor stop,
as well as to change the rotation speed of the motor.
95
Function parameters
Default Modif
value y
0.50
○
Hz/s
0.50
○
Hz/s
0x000
○
0°
○
0.0°
○
0
●
