Goodrive35 Series Closed-loop Vector Control VFD
Function
code
P02.00 Motor type 1
Rated power of
P02.01
asynchronous motor 1
Rated frequency of
P02.02
asynchronous motor 1
Rated speed of
P02.03
asynchronous motor 1
Rated voltage of
P02.04
asynchronous motor 1
Rated current of
P02.05
asynchronous motor 1
Rated power of
P02.15
synchronous motor 1
Rated frequency of
P02.16
synchronous motor 1
Number of poles pairs
P02.17
for synchronous motor 1
Rated voltage of
P02.18
synchronous motor 1
Rated current of
P02.19
synchronous motor 1
Multi-function digital
P05.01–P input terminals
05.09 (S1–S8,HDI) function
P07.01 Parameter copy
Name
3: Static autotuning 2 (autotune part parameters)
0: Asynchronous motor
1: Synchronous motor
0.1–3000.0 kW
0.01 Hz–P00.03 (max. output frequency)
1–36000 rpm
0–1200 V
0.8–6000.0 A
0.1–3000.0 kW
0.01 Hz–P00.03 (max. output frequency)
1–128
0–1200 V
0.8–6000.0 A
36: Shift the command to keypad
37: Shift the command to terminals
38: Shift the command to communication
selection
The function code determines the manner of
parameters copy.
0: No operation
1: Upload the local function parameter to the
keypad
2: Download the keypad function parameter to
local address (including the motor parameters)
3: Download the keypad function parameter to
local address (excluding the motor parameter of
P02 and P12 group)
Detailed instruction of parameters
138
Basic operation instruction
Default
value
1
Depend on
model
50.00 Hz
Depend on
model
Depend on
model
Depend on
model
Depend on
model
50.00 Hz
2
Depend on
model
Depend on
model
0
