INVT Goodrive35 Series Operation Manual page 117

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Initial pole position of
P12.24
SM 2 (reserved)
Identification current
P12.25
of SM 2 (reserved)
Motor 2 overload
P12.26
protection
Motor 2 overload
P12.27
protection coefficient
Detailed instruction of parameters
force constant can be
counted according to the
parameters on the name
plate of the motor. There
are three ways to count:
1. If the name
designate
counter-electromotive
force constant Ke, then:
E= (Ke*n *2π)/ 60
N
2. If the name
designate
counter-electromotive
force constant
(V/1000r/min), then:
E=E'*n /1000
N
3. If the name plate does
not designate the above
parameters, then:
E=P/√3*I
In the above formulas: n
is the rated rotation
speed, P is the rated
power and I is the rated
current.
Setting range: 0–10000
0–FFFFH (reserved)
0%–50% (the rated current of the motor) (reserved)
0: No protection
1: Common motor (with low speed compensation)
2: Variable-frequency motor (without low speed
compensation)
Motor overload multiple M = Iout/(In × K)
In is the rated current of the motor, Iout is the output
current of the VFD and K is the motor overload
protection coefficient.
110
updated
autotuning
automatically, and there
is no need to change
the value of P12.23;
plate when P00.15=2, the set
the value of P12.23 cannot
be updated
autotuning,
account and update the
plate value of P12.23.
the Note: Users
modify the parameters
E' freely.
N
Function parameters
Default Modif
value
through
through
please
cannot
0x0000
10%
2
100.0%
y
●
●
◎
○
