INVT Goodrive35 Series Operation Manual page 148

Goodrive35 Series Closed-loop Vector Control VFD
Function
code
High-point frequency for
P03.05
P03.06
Compensation coefficient of
P03.07
electromotion slip
Compensation coefficient of
P03.08
P03.09 ACR proportional coefficient P 0–20000
P03.10 ACR integral coefficient I
P03.11 Torque setting method
P03.12 Keypad setting torque
P03.13 Torque reference filter time
Upper frequency of forward
P03.14
rotation in vector control
Name
switching
ASR output filter
brake slip
Detailed instruction of parameters
P03.02–P00.03 (max. output frequency)
0–8 (corresponds to 0–2
50%–200%
50%–200%
0–20000
0: Torque control is invalid
1: Keypad setting torque (P03.12)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8: PROFIBUS/CANopen communication
setting torque (the same as above)
9: Ethernet communication setting torque
(the same as above)
10: Reserved
Note: Setting modes
corresponds to three times of the rated
current of the motor.
-300.0%–300.0% (rated motor current)
0.000–10.000s
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI setting upper-limit
frequency
5: Multi-step setting upper-limit frequency
6: Modbus communication
upper-limit frequency
7: PROFIBUS/CANopen communication
setting upper-limit frequency
141
Basic operation instruction
8
/10 ms)
2–10, 100%
setting
Default
value
10.00 Hz
0
100%
100%
1000
1000
0
10.0%
0.100 s
