Analog Input - INVT Goodrive35 Series Operation Manual

Goodrive35 Series Closed-loop Vector Control VFD
Function
code
UP terminals frequency
P08.45
changing ratio
DOWN terminals
P08.46
frequency changing ratio
P17.00 Setting frequency
P17.02 Ramp reference frequency
P17.14 Digital adjustment

7.9 Analog input

Goodrive35 series VFDs have three analog input terminals and 1 high-speed pulse input terminals (of
which, AI1 and AI2 are 0–10 V/0–20mA and Al can select voltage input or current input by J3, AI2 can
select voltage input or current input by J4 and AI3 is for -10–10 V) as the standard configuration. The
inputs can be filtered and the maximum and minimum values can be adjusted.
Name
0: UP/DOWN terminals setting valid
1: UP/DOWN terminals setting valid
LED tens: Frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: All frequency means are valid
2: Invalid for multi-step speed when multi-step
speed takes priority
LED hundreds: Action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving
the stop commands
0.01–50.00 Hz/s
0.01–50.00 Hz/s
Range:
frequency)
Range:
frequency)
0.00 Hz–P00.03
Detailed instruction of parameters
0.00 Hz–P00.03
0.00 Hz–P00.03
164
Basic operation instruction
Default
value
0.50 Hz/s
0.50 Hz/s
(max. output
0.00 Hz
(max. output
0.00 Hz
0.00 Hz
