Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Polarity selection of
P05.10
the input terminals
P05.11 ON-OFF filter time
Virtual terminals
P05.12
setting
Detailed instruction of parameters
control
52: Pulse input disabled
53: Position deviation clear
54: Position proportional gain switch
55: Digital position cycle positioning enabled
56: E-stop
57: Motor overtemperature fault input
58: Rigid tapping enable
59: Switch to SVPWM control
60: Switch to FVC control
61: PID pole switching
62: Undervoltage stopping input
63: Servo enabling
The function code is used to set the polarity of the
input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT8
HDI
BIT4 BIT3
S5 S4
The setting range: 0x000–0x1FF
Set the sample filter time of S1–S8 and HDI
terminals. If the interference is strong, increase the
parameter to avoid the disoperation.
0.000–1.000s
0x000–0x1FF (0: Disabled, 1: Enabled )
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: S5 virtual terminal
BIT5: S6 virtual terminal
BIT6: S7 virtual terminal
BIT7: S8 virtual terminal
BIT8: HDI virtual terminal
Note: After a virtual terminal is enabled, the state of
the terminal can
74
BIT7 BIT6
S8 S7
BIT2 BIT1
S3 S2
only be modified
Function parameters
Default Modif
value
BIT5
0x000
S6
BIT0
S1
0.010 s
0x000
through
y
○
○
◎
