INVT Goodrive35 Series Operation Manual page 141

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
angle 2
Spindle indexing
P22.09
angle 3
Spindle indexing
P22.10
angle 4
Spindle indexing
P22.11
angle 5
Spindle indexing
P22.12
angle 6
Spindle indexing
P22.13
angle 7
P22.14 Spindle drive ratio
Spindle zero-point
P22.15 communication
setting
Detailed instruction of parameters
Range: 0.00–359.99
Range: 0.00–359.99
Range: 0.00–359.99
Range: 0.00–359.99
Range: 0.00–359.99
This parameter is used to set the deceleration ratio
of the spindle to shaft where the encoder is mounted.
Range: 0.000–30.000
P22.15 is used to set the zero-point offset of the
spindle. If you set P22.03 as the zero point of the
spindle, the final zero point of the spindle is P22.03
plus P22.15.
Range: 0–39999
134
Function parameters
Default Modif
value y
45.00
○
60.00
○
90.00
○
120.00
○
180.00
○
1.000
○
0
○
