INVT Goodrive35 Series Operation Manual page 125

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
P16.06 Subnet mask 2
P16.07 Subnet mask 3
P16.08 Subnet mask 4
P16.09 Gateway 1
P16.10 Gateway 2
P16.11
Gateway 3
P16.12
Gateway 4
P17 Group Monitoring function
P17.00 Setting frequency
P17.01 Output frequency
Ramp reference
P17.02
frequency
P17.03 Output voltage
P17.04 Output current
P17.05 Motor speed
P17.06 Torque current
P17.07 Exciting current
P17.08 Motor power
P17.09 Output torque
Detailed instruction of parameters
Set the subnet mask of Ethernet communication.
The format
P16.13.P16.14.P16.15.P16.16.
For example: The mask is 255.255.255.0.
0–255
Set the gateway of Ethernet communication
Display current set frequency of the VFD
Range: 0.00 Hz–P00.03
Display current output frequency of the VFD
Range: 0.00 Hz–P00.03
Display current ramp reference frequency of the
VFD
Range: 0.00 Hz–P00.03
Display current output voltage of the VFD
Range: 0–1200 V
Display present output current of the VFD
Range: 0.0–5000.0 A
Display the rotation speed of the motor.
Range: 0–65535 RPM
Display present torque current of the VFD
Range: -3000.0–3000.0 A
Display present exciting current of the VFD
Range: -3000.0–3000.0 A
Display present power of the motor.
Setting range: -300.0%–300.0% (rated power of the
motor)
Display the current output torque of the VFD; 100%
relative to rated torque of the motor. During forward
running, the positive value is the motoring state while
the negative value is generating state. During
reverse running, the positive value is the generating
state while the negative value is the motoring state.
Range: -250.0–250.0%
118
of IP subnet
Function parameters
Default Modif
value y
◎
255
mask:
◎
255
◎
0
◎
192
◎
168
◎
1
◎
1
0.00 Hz
●
0.00 Hz
●
0.00 Hz
●
0 V
●
0.0 A
●
0 RPM
●
0.0 A
●
0.0 A
●
0.0%
●
0.0% ●
