Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Autotuning of
P20.11 magnetic pole initial
angle
Encoder signal filter
P20.12
width
Speed optimization
P20.13
enabling
P21 Position control
P21.00 Positioning mode
Detailed instruction of parameters
encoder and the magnetic pole position of the motor.
Setting range: 0.00–359.99
Setting range: 0–3
0: No operation
1: Rotary autotuning (no load)
2: Static autotuning (fit for resolver and sin/cos
encoder)
3: Rotary autotuning (loaded)
After setting the value to 1 or 2, the keypad will
display "-RUN-", then press "RUN" to begin the
autotuning until the keypad display "-END-". The
identified initial angle is saved in P20.09 and P20.10.
The pole initial angle obtained from rotary autotuning
1 is more accurate. Generally it is necessary to
de-couple the motor or lighten the motor load for
rotary autotuning.
Range: 0.0–20.0us
0: Disabled
1: Enabled
Setting range: 0x00–0x21
Ones: Control mode setting, setting the position
control mode in closed-loop vector control.
0: Speed control
1: Position control
Tens: Position command source
0: Pulse string, adopting terminal pulse signals A2
and B2 to implement positioning control
1: Digital position. Positioning through P21.17 and
the positioning modes can be set through P21.16
2: Photoelectric switch positioning. After the terminal
receives the signal (set S8 to 43), the stopping
positioning begins and the stopping distance is set
through P21.17.
Hundreds: Reserved
Thousands: Servo mode
Bit0：Position deviation mode
125
Function parameters
Default Modif
value y
0
◎
0.5 us
○
0–1 ◎
