B frequency
P00.08
command reference
Detailed instruction of parameters
(HDI high speed pulse input function selection) to
frequency setting input.
5: Simple PLC program setting
The VFD runs at simple PLC program mode when
P00.06=5 or P00.07=5. Set P10 (simple PLC and
multi-step speed control) to select the running
frequency, running direction, ACC/DEC time and the
keeping time of corresponding stage. See the
function description of P10 for detailed information.
6: Multi-step speed running setting
The VFD runs at multi-step speed mode when
P00.06=6 or P00.07=6. Set P05 to select the current
running stage, and set P10 to select the current
running frequency.
The multi-step speed has the priority when P00.06 or
P00.07 does not equal to 6, but the setting stage can
only be the 1–15 stage. The setting stage is 0–15 if
P00.06 or P00.07 equals to 6.
7: PID control setting
The running mode of the VFD is process PID control
when P00.06=7 or P00.07=7. It is necessary to set
P09. The running frequency of the VFD is the value
after PID effect. See P09 for the detailed information
of the given source, given value, feedback source of
PID.
8: Modbus communication setting
The frequency is set by Modbus communication.
See P14 for detailed information.
9: PROFIBUS/CANopen communication setting
The frequency is set by PROFIBUS/ CANopen
communication. See
information.
10: Ethernet communication setting (reserved)
See P16 for the detailed information.
11: Reserved
12: Pulse string AB setting
0: Maximum output frequency, 100% of B frequency
setting corresponds
49
P15 for the
to the maximum
Function parameters
Default Modif
value
detailed
0
output
y
○
