Goodrive35 Series Closed-loop Vector Control VFD
Model
GD35-220G-6-C1/D1/H1
GD35-250G-6-C1/D1/H1
GD35-280G-6-C1/D1/H1
GD35-315G-6-C1/D1/H1
GD35-350G-6-C1/D1/H1
GD35-400G-6-C1/D1/H1
GD35-500G-6-C1/D1/H1
GD35-560G-6-C1/D1/H1
GD35-630G-6-C1/D1/H1
Note:
1. The input current of VFDs 22–350 kW is detected when the input voltage is 660 V and there is no
DC reactors and input/output reactors.
2. The input current of VFDs 400–630 kW is detected when the input voltage is 660 V and there are
input reactors.
3. The rated output current is defined when the output voltage is 660 V.
4. The output current cannot exceed the rated output current and the output power cannot exceed the
rated output power in the voltage range.

3.7 Structure diagram

The VFD layout is shown below (take 380 V 30 kW as an example).
Output Input current
power (kW) (A)
220 230
250 255
280 286
315 334
350 360
400 411
500 518
560 578
630 655
13
Output current Carrier frequency
(A)
240
274
300
328
380
426
540
600
680
Product overview
( kHz)
1–15 (2)
1–15 (2)
1–15 (2)
1–15 (2)
1–15 (2)
1–15 (2)
1–15 (2)
1–15 (2)
1–15 (2)
