Goodrive35 Series Closed-loop Vector Control VFD

Appendix D Optional peripheral accessories

D.1 What this chapter contains
This chapter describes how to select the options and parts of Goodrive35 series.
D.2 Peripheral wiring
Below is the peripheral wiring of Goodrive35 series VFDs.
LED keypad
Standard
Power
supply
Breaker
Input reactor
Input filter
Note:
1. Built-in brake unit is included for 380 V 30 kW and below models;
2. P1 terminal is included for 380 V 37 kW and above models, which can be connected to external DC
reactor directly;
LCD keypad
Optional
P1
+
DC reactor
Grounding
+
RS485 to
485
RS232
-
converter
485
PB
Brake
resistor
Output filter
Output reactor
270
Optional peripheral accessories
Upper PC
software
PC
-
+ +
Brake unit
Motor
Grounding
