Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
STOP/RST stop
P07.04
function
P07.05 Parameters state 1
P07.06 Parameters state 2
Parameters for
P07.07
stopping state
Detailed instruction of parameters
STOP/RST is valid for stop function. STOP/RST is
valid in any state for the fault reset.
0: Only valid for the keypad control
1: Both valid for keypad and terminals control
2: Both valid for keypad and communication control
3: Valid for all control modes
0x0000–0xFFFF
BIT0: Running frequency (Hz on)
BIT1: Set frequency (Hz flickering)
BIT2: Bus voltage (Hz on)
BIT3: Output voltage (V on)
BIT4: Output current (A on)
BIT5: Running rotation speed (rpm on)
BIT6: Output power (% on)
BIT7: Output torque (% on)
BIT8: PID reference (% flickering)
BIT9: PID feedback value (% on)
BIT10: Input terminals state
BIT11: Output terminals state
BIT12: Torque set value (% on)
BIT13: Pulse counter value
BIT14: Length value
BIT15: PLC and the current stage in multi-step
speed
0x0000–0xFFFF
BIT0: AI1 (V on)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: HDI frequency
BIT4: Motor overload percentage (% on)
BIT5: VFD overload percentage (% on)
BIT6: Ramp frequency given value (Hz on)
BIT7: Linear speed
BIT8: AC inlet current (A on)
BIT9–15: Reserved
0x0000–0xFFFF
BIT0: Set frequency (Hz on, frequency flickering
slowly)
85
Function parameters
Default Modif
value y
0
○
0x03FF
○
0x0000
0x00FF
○
