3.5 Model code

The model code contains information on the VFD. The user can find the model code from the
nameplate on the the VFD or from the simplified nameplate.
Key Sign
Abbreviation
①
Rated power ②
Voltage
③
degree
Lot number
④

3.6 Rated values

3.6.1 Rated value of AC 3PH 380 V (-15%)–440 V (+10%)
Model
GD35-1R5G-4-C1/D1/H1
GD35-2R2G-4-C1/D1/H1
GD35-004G-4-C1/D1/H1/H2/S1
GD35-5R5G-4-C1/D1/H1/H2/S1
GD35-7R5G-4-C1/D1/H1/H2/S1
GD35-011G-4-C1/D1/H1/H2/S1
GD35-015G-4-C1/D1/H1/H2/S1
GD35-018G-4-C1/D1/H1/H2/S1
GD35-022G-4-C1/D1/H1/H2/S1
GD35–5R5G–4–H1
①
Figure 3-5 Model code
Instruction
Abbreviation Goodrive35: Goodrive35 close-loop vector control VFDs
5R5-5.5 kW
Power + Load
G—constant torque load
4: AC 3PH 380 V (-15%)–440 V (+10%)
Rated voltage: 380 V
Voltage degree
6: AC 3PH 520 V (-15%)–690 V (+10%)
Rated voltage: 660 V
C1: Support 24 V incremental encoder
D1: Support rotary transformer
Optional PG cards with functions of pulse and direction
pulse input reference
H1: Support 5 V/12 V incremental encoder, differential,
push-pull, and open collector signals;
Lot number Pulse + direction pulse input reference
H2: Support 5 V incremental encoder for high-speed
differential signal processing;
Pulse + direction pulse input reference (specific for
machine tools)
S1: Support sin/cos encoder, sin/cos (1 Vpp) eg
Heidenhain ERN1387; support quadrature pulse input
power (kW)
②
③
Output Input current
(A)
1.5 5.0
2.2 5.8
4 13.5
5.5 19.5
7.5 25
11 32
15 40
18.5 47
22 56
11
Product overview
④
Content
Output
current (A) frequency (kHz)
3.7
5
9.5
14
18.5
25
32
38
45
Carrier
1–15 (8)
1–15 (8)
1–15 (8)
1–15 (8)
1–15 (8)
1–1s5 (8)
1–15 (4)
1–15 (4)
1–15 (4)
