INVT Goodrive35 Series Operation Manual page 86

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
HDI high-speed
P05.49
pulse input function
Lower limit frequency
P05.50
of HDI
Corresponding
P05.51 setting of HDI low
frequency
Upper limit frequency
P05.52
of HDI
Corresponding
P05.53 setting of upper limit
frequency of HDI
HDI frequency input
P05.54
filter time
P06 Group Output terminals
P06.00 HDO output
Detailed instruction of parameters
The setting range of P05.37: 0.00 V–P05.39
The setting range of P05.38: -300.0%–300.0%
The setting range of P05.39: P05.37–10.00 V
The setting range of P05.40: -300.0%–300.0%
The setting range of P05.41: 0.000s–10.000s
The setting range of P05.42: -10.00 V–P05.44
The setting range of P05.43: -300.0%–300.0%
The setting range of P05.44: P05.42–P05.46
The setting range of P05.45: 0.00–10.00 V
The setting range of P05.46: P05.44–10.00 V
The setting range of P05.47: -300.0%–300.0%
The setting range of P05.48: 0.000s–10.000s
The function selection when HDI terminals is
high-speed pulse input
0: Frequency setting input, frequency setting source
1–2: Reserved
0.000 kHz–P05.52
-300.0%–300.0%
P05.50–50.000 kHz
-300.0%–300.0%
0.000s–10.000s
The function selection of the high-speed pulse
output terminals.
0: Open collector pole high speed pulse output: The
Max pulse frequency
P06.27–P06.31 for detailed information of the
related functions.
1: Open collector pole output. See P06.02 for
detailed information of the related functions.
79
is 50.0 kHz. See
Function parameters
Default Modif
value y
0 ◎
0.000
○
kHz
0.0%
○
50.000
○
kHz
100.0%
○
0.030s
○
0
◎
