INVT Goodrive35 Series Operation Manual page 186

Goodrive35 Series Closed-loop Vector Control VFD
Set
value
13 Pre-exciting
14 Overload pre-alarm
15 Underload pre-alarm
16 Simple PLC stage completion Output signal if the simple PLC stage is completed.
Simple PLC cycle
17
completion
Modbus communication
23
virtual terminal output
POROFIBUS/CANopen
24 communication virtual
terminal output
Ethernet communication
25
virtual terminal output
26 Bus voltage established
27–29 Reserved
30 Positioning finished
31 Spindle returning finished
32 Spindle scaling finished
33 Speed limiting
34 Low bus voltage
35 Underload stopping output
Speed/position switching
36
Relative parameters list:
Function
code
P06.00
P06.01
Function
finished
Name
HDO output
Y1 output
Output ON signal when the VFD is in the pre-exciting
state.
Output ON signal if the VFD is beyond the pre-alarm point.
Refer to P11.08–P11.10 for the detailed instruction.
Output ON signal if the VFD is beyond the pre-alarm point.
Refer to P11.11–P11.12 for the detailed instruction.
Output signal if the 1 simple PLC cycle is completed.
Output corresponding signal according to the setting value
of Modbus. Output ON signal if the setting value is 1 and
output OFF signal if the setting value is 0.
Output corresponding signal according to the setting value
of PROFIBUS/CANOPEN. Output ON signal if the setting
value is 1 and output OFF signal if the setting value is 0.
Output the corresponding signal according to the Ethernet
signal. Output ON when setting as1 and output OFF when
setting as 0.
Output ON according to the establishment of bus voltage
Output ON when the positioning is finished
Output ON when the returning is finished
Output ON when the scaling is finished
Output ON when the speed is the upper or lower limit
Output ON when the value is below P8.27
If enabling bit of P08.26 is valid, and it is in underload
state, ON signal will be output
When the speed is switched to position control, output ON
signal
Detailed instruction of parameters
0: Open collector pole high speed pulse
output
1: Open collector pole output
0: Invalid
179
Basic operation instruction
Instructions
Default
value
0
0
