Goodrive35 Series Closed-loop Vector Control VFD
1.4 Safety guidelines
1.4.1 Delivery and installation
Note:
Select appropriate moving and installing tools to ensure a safe and normal running of the VFD
and avoid physical injury or death. For physical safety, the erector should take some
mechanical protective measurements, such as wearing exposure shoes and working uniforms.
Ensure to avoid physical shock or vibration during delivery and installation.
Do not carry the VFD by its cover. The cover may fall off.
Only qualified electricians are allowed to operate on the VFD.
Do not carry out any wiring and inspection or changing components when
the power supply is applied. Ensure all input power supply is disconnected
before wiring and checking and always wait for at least the time designated
on the VFD or until the DC bus voltage is less than 36 V. Below is the table of
the waiting time:
VFD module
380 V
1.5 kW-110 kW
380 V
132 kW -315 kW
660 V
22 kW-132 kW
660 V
160 kW-350 kW
660 V
400 kW-630 kW
Do not refit the VFD unless authorized; otherwise fire, electric shock or other
injury may occur.
The base of the radiator may become hot during running. Do not touch to
avoid hurt.
The electrical parts and components inside the VFD are electrostatic. Take
measurements to avoid electrostatic discharge during relevant operation.
Please install the VFD on fire-retardant material and keep the VFD away
from combustible materials.
Connect the brake optional parts (brake resistors, brake units or feedback
units) according to the wiring diagram.
Do not operate on the VFD if there is any damage or components loss to the
VFD.
Do not touch the VFD with wet items or your body, otherwise electric shock
may occur.
Minimum waiting time
2
Safety precautions
5 minutes
15 minutes
5 minutes
15 minutes
25 minutes
