Goodrive35 Series Closed-loop Vector Control VFD
Set value
7
8 Operation pause
9 External fault input
10 Frequency setting up (UP) This parameter is used to modify the increasing and
Frequency setting down
12
12 increasing/decreasing
Switch between A setting
13
Switch between A setting
14
and combination setting
Switch between B setting
15
and combination setting
16
Multi-step speed terminal 1 The 16 stage speeds can be set by the combination of
17 Multi-step speed terminal 2
18
Multi-step speed terminal 3
19
Multi-step speed terminal 4
Function
Fault reset
(DOWN)
Frequency
setting clear
and B setting
External fault reset. It has the same function with the reset
function of STOP/RST on the keypad. This function can
realize remote fault reset.
The VFD decelerates to stop. But all running parameters
are in the memory state. For example, PLC parameters,
traverse parameters and PID parameters. After the signal
disappears, the VFD will come back to the state before
stopping.
When the external fault signal is sent to the VFD, the VFD
will report the fault and stop.
decreasing command during the external terminal given
frequency.
K1
K2
K3
Frequency increasing/decreasing setting clear terminal
can cancel the assistant channel frequency set by the
internal UP/DOWN of the VFD to make the given
frequency restore to the frequency given by the main
given frequency channel.
This function can realize the shifting between the
frequency setting channels.
th
The 13 function can realize the shifting between A
frequency given channel and B frequency given channel.
th
The 14 function can realize the shifting between A
frequency given channel and the combination setting
channel set by P00.09. The 15
shifting between B frequency given channel and the
combination setting channel set by P00.09.
digital state of four terminals.
Note: Multi-step speed 1 is the LSB; multi-step speed 4 is
the MSB.
171
Basic operation instruction
Instructions
UP terminal
DOWN terminal
UP/DOWM
clear terminal
COM
th
function can realize the
