INVT Goodrive35 Series Operation Manual page 259

Goodrive35 Series Closed-loop Vector Control VFD
Request label (From master to slave)
Request
0
1
Modification parameter value (one word)
2
Modification parameter value (double word)
3
Modification parameter value (one word)
4
[RAM and EEPROM are modified]
Modification parameter value (double word)
5
[RAM and EEPROM are modified]
Request label "2"-modification parameter value (one word) [only change RAM]; "3"-modification
parameter value (double word) [only change RAM]; "5"-modification parameter value (double word)
[RAM and EPROM are modified] not support currently.
Reponses logo PKW1 defines as below:
Confirmation
0
1
2
3
4
Function
No task
Request parameter value
[only change RAM]
[only change RAM]
Response label (From slave to master)
No response
Transmission parameter value (one word)
Transmission parameter value (two words)
Task cannot be executed and returns the following error number:
0: Illegal parameter number
1: Parameter values cannot be changed (read-only parameter)
2: Out of set value range
3: The sub-index number is not correct
4: Setting is not allowed (only reset)
5: Data type is invalid
6: The task could not be implemented due to operational state
7: Request isn't supported.
8: Request can't be completed due to communication error
9: Fault occurs when write operation to stationary store
10: Request fails due to timeout
11: Parameter cannot be assigned to PZD
12: Control word bit can't be allocated
13: Other errors
No parameter change rights
Positive
confirmation
1,2
Function
252
Extension card
Response label
Negative
confirmation
0
－
3
1 3 or 4
2 3 or 4
1 3 or 4
2 3 or 4
