Goodrive35 Series Closed-loop Vector Control VFD
Function
code
upper frequency of
reverse rotation
Upper electromotion
P03.18
torque source
Upper brake torque
P03.19
Keypad setting of
P03.20
electromotion torque
Keypad setting of brake
P03.21
P17.09 Output torque
P17.15 Torque reference

7.6 Parameters of the motor

 Physical accident may occur if the motor starts up suddenly during autotune.
Please check the safety of surrounding environment of the motor and the load
Name
0:
(P03.20)
1: AI1 (100% corresponds to three times of the
rated current of the motor)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: HDI (the same as above)
5: Modbus communication (the same as
above)
6: PROFIBUS/CANopen communication (the
same as above)
7: Ethernet communication (the same as
above)
0:
(P03.21)
1: AI1 (100% corresponds to three times of the
rated current of the motor)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: HDI (the same as above)
source
5: Modbus communication (the same as
above)
6: PROFIBUS/CANopen communication (the
same as above)
7: Ethernet communication (the same as
above)
0.0–300.0% (rated current of the motor)
0.0–300.0% (rated current of the motor)
torque
-250.0–250.0%
-300.0–300.0% (rated current of the motor)
Detailed instruction of parameters
Keypad setting upper-limit
Keypad setting upper-limit
151
Basic operation instruction
Default
value
frequency
0
frequency
0
180.0%
180.0%
0.0%
0.0%
