INVT Goodrive35 Series Operation Manual page 57

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Combination of
P00.09
setting source
Keypad set
P00.10
frequency
P00.11 ACC time 1
P00.12 DEC time 1
P00.13 Running direction
Detailed instruction of parameters
frequency
1: A frequency command, 100% of B frequency
setting corresponds
frequency. Select this setting if it needs to adjust on
the base of A frequency command
0: A, the current frequency setting is A frequency
command
1: B, the current frequency setting is B frequency
command
2: A+B, the current frequency setting is A frequency
command + B frequency command
3: A-B, the current frequency setting is A frequency
command - B frequency command
4: Max (A, B): The bigger one between A frequency
command and B frequency is the set frequency.
5: Min (A, B): The lower one between A frequency
command and B frequency is the set frequency.
Note: The combination manner can be shifted by
P05 (terminal function)
When A and B frequency commands are selected as
"keypad setting", the value of the function code is the
original setting one of the frequency data of the VFD.
Setting range: 0.00 Hz–P00.03 (max. output
frequency)
ACC time means the time needed if the VFD speeds
up from 0 Hz to max. output frequency (P00.03).
DEC time means the time needed if the VFD speeds
down from max. output frequency to 0 Hz (P00.03).
Goodrive35 series VFDs define four groups of
ACC/DEC time which can be selected by P05. The
factory default ACC/DEC time of the VFD is the first
group.
Setting range of P00.11 and P00.12: 0.0–3600.0s
0: Runs at the default direction, the VFD runs in the
forward direction. FWD/REV indicator is off.
1: Runs at the reverse direction, the VFD runs in the
reverse direction. FWD/REV indicator is on.
50
to the maximum
Function parameters
Default Modif
value y
output
○
0
50.00
○
Hz
Depend
○
on model
Depend
○
on model
○
0
