Goodrive35 Series Closed-loop Vector Control VFD
R
S
T
PE
Figure 3-3 The simplified main circuit diagram (VFDs of 660 V)
Note:
1. The VFDs of 380 V (≥37 kW) supports external DC reactors and external brake units, but it is
necessary to remove the copper tag between P1 and (+) before connecting. DC reactors and brake
units are optional.
2. The VFDs of 380 V (≤30 kW) supports external brake resistors which are optional.
3. The VFDs of 660 V supports external DC reactors and external brake units, but it is necessary to
remove the copper tag between P1 and (+) before connecting. DC reactors and brake units are
optional.

3.3 Product specification

Function
Power input
Input frequency (Hz)
Output voltage (V)
Output current (A)
Power output
Output power (kW)
Output frequency (Hz) 0–400 Hz
Technical
control
feature
Adjustable-speed ratio
DC reactor
P1
Input voltage (V)
Input current (A)
Control mode
Motor type
（+）
（-）
AC 3PH 380 V (-15%)–440 V (+10%)
Rated voltage: 380 V
AC 3PH 520 V (-15%)–690 V (+10%)
Rated voltage: 660 V
Refer to section 3.6 "Rated values"
50 Hz or 60 Hz
Allowed range: 47–63 Hz
0–input voltage
Refer to section 3.6 "Rated values"
Refer to section 3.6 "Rated values"
SVPWM, SVC and VC
Asynchronous motor
synchronous motor
Asynchronous motor 1: 200 (SVC) synchronous motor 1:
20 (SVC) 1: 1000 (VC)
8
Product overview
PE
Specification
and permanent
U
V
W
magnet
