INVT Goodrive35 Series Operation Manual page 97

Goodrive35 Series Closed-loop Vector Control VFD
Functio
Name
n code
Overvoltage stall
P08.15
modulator gain
P08.16 ASR differential gain Setting range: 0.00–10.00s
Max torque of inertia
P08.17
compensation
Inertia compensation
P08.18
filter times
High-frequency ACR
P08.19 proportional
coefficient
High-frequency ACR
P08.20
integral coefficient
ACR high frequency
P08.21
switching point
Inertia identification
P08.22
torque
P08.23 Inertia identification
P08.24 System inertia
Detailed instruction of parameters
Setting range: 0.00 Hz–P00.03 (max. output
frequency)
Setting range: 0.0–1000.0
Limit the max. inertia compensation torque to
prevent the inertia compensation torque from being
too large.
Setting range: 0.0–150.0% (rated torque of the
motor)
Filter times of inertia compensation torque is used to
smooth the inertia compensation torque.
Setting range: 0–10
In the closed-loop vector control mode (P00.00=3),
when the running frequency is lower than the ACR
high frequency switching point (P08.21), the ACR PI
parameters are P03.09 and P03.10; and when the
running frequency is higher than the ACR high
frequency switching point, the ACR PI parameters
are P08.19 and P08.20.
Setting range of P08.19: 0–20000
Setting range of P08.20: 0–20000
Setting range of P08.21: 0.0–100.0% (relative max
frequency)
Because of the friction, it is necessary to set
identification torque for normal inertia identification.
0.0–100.0% (rated torque of the motor)
0: No operation
1: Starting identification: press "RUN" to enter into
the program after starting identification until display
"-END-"; the identified system inertia is saved in
P08.24.
The identified system inertia can be set manually
when the system inertia is known. The displayed
system inertia may be less than 0.001kgm
motors below 1 kW.
Setting range: 0.000–30.000 kgm
90
Function parameters
2
for the
2
Default Modif
value y
12.0
○
0.00 s
○
20.0%
○
7
○
1000
○
1000 ○
100.0%
○
10.0%
◎
0
◎
0.000
○
2
kgm
