Goodrive35 Series Closed-loop Vector Control VFD
Function
code
Multi-function digital input
P05.01–P
05.09 (S1–S8,HDI) function
P08.42 Keypad data control
Integral ratio of the keypad
P08.43
potentiometer
UP/DOWN terminals
P08.44
Name
3: (A-B) combination
4: Max (A, B) combination
5: Min (A, B) combination
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
terminals 13: Shift between A setting and B setting
14: Shift between combination setting and A
selection setting
15: Shift between combination setting and B
setting
0x000–0x1223
LED ones: Frequency enable selection
0: Both ∧/∨ keys and digital potentiometer
adjustments are valid
1: Only ∧/∨ keys adjustment is valid
2: Only digital potentiometer adjustments is
valid
3:
potentiometer adjustments are valid
LED tens: Frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: Action during stopping
0: Setting is valid
1: Valid during running, cleared after stopping
2:
receiving the stop command
LED thousands: ∧ / ∨ keys and digital
potentiometer Integral function
0: The Integral function is valid
1: The Integral function is invalid
0.01–10.00 Hz/s
0x00–0x221
control LED ones: Frequency control selection
Detailed instruction of parameters
Neither ∧ / ∨
Valid during running,
163
Basic operation instruction
keys nor digital
cleared after
Default
value
0x0000
0.10 Hz/s
0x000
