Goodrive35 Series Closed-loop Vector Control VFD
Model
132 kW–200 kW
Model
220 kW–280 kW
315 kW
Figure C-5 Wall installation of 380 V 132-200 kW VFDs
W1
W2
H1
500
180
870
Figure C-6 Wall installation of 380 V 220-315 kW VFDs
W1
W2
H1
680
230
960
680
230
960
H2
D1
850
360
H2
D1
926
380
926
380
263
Dimension drawings
Installation
Weight
hole
(kg)
11
85
Installation
Weight
hole
(kg)
13
135
13
137
