HEIDENHAIN MANUALplus 620 Technical Manual page 513

Parameter
MP number
iTNC MP number
isHirth
300103
MP420
(optional parameter)
axisHw
300104
January 2012
Function and input
Axis with Hirth coupling
Default grid increment in [°] or [mm] for Hirth
coupling, measured from the machine datum.
If the parameter is inactive or the value 0 is
entered, no Hirth grid is supported.
Format: Numerical value
Input: Hirth grid in [°] or [mm]
Hardware to which the axis is connected
Format: Selection menu
Input:
None:
No hardware connection (virtual axis)
InOutCC:
Digital axis with connection to a CC controller
unit
AnalogMC:
Analog drive interface; encoder connection to
the MC
AnalogCC:
Analog drive interface; encoder connection to
the CC
DisplayMC:
Display axis; encoder connection to the MC
DisplayCC:
Display axis; encoder connection to the CC
ManualMC:
Open-loop axis; encoder connection to the MC
ManualCC:
Open-loop axis; encoder connection to the CC
ProfiNet:
Digital Profinet axis (reserved, function not
available yet)
Default: InOutCC
4.10 List of Machine Parameters
Reaction/ Page
Access
RUN 703
LEVEL3
597 110-02
RESET 635
LEVEL3
513
