Machine
parameters
860
MP_vCtrlFiltType1...5
Filter type for filters 1 to 5
Format: Numerical value
Input: 0 to 3
0: No filter
1: PT low-pass filter (speed controller)
2
2: Band-rejection filter (speed ctrlr.)
11: PT low-pass filter (position controller)
2
12: Band-rejection filter (position ctrl.)
Default: 0
Access: LEVEL3
Reaction: RUN
MP_vCtrlFiltFreq1...5
Center frequency of band-rejection filter for filters 1 to 5
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 000 to 5000 [Hz]
Default: 0 [Hz]
Access: LEVEL3
Reaction: RUN
MP_vCtrlFiltBandWidth1...5
Bandwidth of band-rejection filter for filters 1 to 5
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 000 to 5000 [Hz]
Default: 0 [dB]
Access: LEVEL3
Reaction: RUN
MP_vCtrlFiltDamping1..5
Damping of band-rejection filter for filters 1 to 5
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 000 to 40 [dB]
Default: 0 [dB]
Access: LEVEL3
Reaction: RUN
