HEIDENHAIN MANUALplus 620 Technical Manual page 637

Assigning
parameter sets
Virtual axis
January 2012
In MP_parList enter the key name of the parameter set that is assigned to this
axis. The parameter set describes the axis control response, the encoder
connection, the encoder signals, etc.
You can create more than one parameter set for one axis. This enables you to
define different controller settings, for example.
Examples:
a) You define different controller settings to ensure appropriate control
response depending on the load.
b) The spindle and the C axis are realized by using a physical axis. This enables
you to define separate parameter sets for the spindle and the C axis.
MP_parList
List of all parameter sets of this axis
Available from NCK software version: 597 110-01.
Format: Array [0...9]
Input: Key name of the parameter set
Max. 18 characters
e.g.: ParSetX-0 or PX (parameter set for the X axis)
Default: –
Access: LEVEL3
Reaction: RESET
Note
The first parameter set must be fully defined. In KeySynonym/
CfgKeySynonym, you can relate the other parameter sets to the first one.
Then you only have to define the parameters that differ from the ones of
the parameter set to which you have related the present parameter set.
In MP_realAxis, enter the key name of the associated real axis.
For virtual axes, see "Configuration of Axes" on page 624.
MP_realAxis
Key name of the associated real axis
Available from NCK software version: 597 110-01.
Format: Selection menu
Selection: The key name of the associated real axis is only to be entered if
the current axis is a virtual axis (e.g. for noncylindrical grinding).
The key names of the axes are taken from the System/CfgAxes/
axisList parameter and automatically shown as a selection
menu.
Default: No value, parameter optional
Access: LEVEL3
Reaction: RESET
6.3 Configuration of Axes 637
