HEIDENHAIN MANUALplus 620 Technical Manual page 506

Parameter
MP number
iTNC MP number
CfgPrefForPolarKin
Settings for the polar kinematics
(optional)
kindOfPref
202301
(optional parameter)
506
Function and input
Behavior of the polar kinematics at radius 0
If the tool center of a machine with polar
kinematics lies exactly on the polar axis (C axis,
radius 0), there are two possibilities for a linear
positioning block: r,phi or -r,phi+180.
Use this parameter to define the behavior of the
MANUALplus 620 if the tool center point path
runs through (crosses) the polar axis.
Format: Selection menu
Input:
RadiusPositive:
After crossover, the tool center point is at a
position with positive radius.
RadiusNegative:
After crossover, the tool center point is at a
position with negative radius.
MinimalAngle:
The crossover path is executed through a C-axis
movement as small as possible.
NoChangeOfRadius:
After crossover, the radius has the same
algebraic sign as before crossover.
Radius0NotAllowed:
A tool center point path that runs through
(crosses) the polar axis is not allowed.
HEIDENHAIN Technical Manual MANUALplus 620
Reaction/ Page
Access
RUN –
LEVEL1
