Machine
parameters for
path-specific limit
values
826
Settings in the configuration editor
Channels
ChannelSettings
[Key name of the machining channel]
CfgLaPath
minPathFeed
minCornerFeed
maxG1Feed
maxPathJerk
maxPathJerkHi
pathTolerance
pathToleranceHi
maxPathYank
 In CfgLaPath, define the path-specific limit values for feed rate, acceleration
and jerk.
MP_minPathFeed allows you to define the minimum feed rate in an NC block.
The parameter is intended for technological purposes, in particular for
preventing dwell marks in small radii. If the values are too large, feed-rate
optimization becomes ineffective. This might lead to excessive dynamic load
on the machine.
Note
MP_minPathFeed is always limited to the programmed feed rate; this
means that look-ahead violates the defined minimum feed-rate value only
if a lower value is programmed in the NC block or is set by the override
potentiometer.
MP_minPathFeed
Minimum feed rate on the path
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: 0.000 000 000 to 600 000 [mm/min]
Default: 60 [mm/min]
Access: LEVEL3
Reaction: RUN
HEIDENHAIN Technical Manual MANUALplus 620
MP number
201501
201502
201503
201504
201505
201506
201507
201508
