If you open the MP_swLimitSwitchNeg or MP_swLimitSwitchPos
parameter in the configuration editor (Machine Parameter Programming
operating mode) you can press the ACTUAL POSITION CAPTURE soft key to
apply the position value of an axis automatically.
The soft key displays a soft-key row showing the available axes. When you
press an axis soft key, the MANUALplus 620 captures the position of the axis
in the REFNOML system.
MP_swLimitSwitchPos
Positive software limit switch
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: –100 000.000 000 000 to +100 000 [mm] or [°]
Default: 0 [mm] or [°]
Access: LEVEL3
Reaction: RUN
MP_swLimitSwitchNeg
Negative software limit switches
Available from NCK software version: 597 110-01.
Format: Numerical value
Input: –100 000.000 000 000 to +100 000 [mm] or [°]
Default: 0 [mm] or [°]
Access: LEVEL3
Reaction: RUN
Note
If positive and negative software limit switches = 0, limit-switch monitoring
is switched off.
