3 Software Architecture
This chapter contains a variety of topics on the software and programming of the device. First, the registers and
their properties are listed in
and addressing modes are described
sion for calculations in the DAU are described in
cusses both the vectored interrupts and the DSP16A compatible interrupts. (The DSP16A compatible interrupts
are available on the DSP1617 only.)
describes the DSP1627/28/29's phase-lock loop based clock synthesizer. And finally, the flexible power manage-
ment features are discussed in

3.1 Register View of the DSP1611/17/18/27/28/29

3.1.1 Types of Registers

Registers are either accessible by the program or through the DSP1611/17/18/27/28/29 pins. Accessible by pro-
gram means they can be selected in data move instructions. The program-accessible registers are denoted by
lower-case names; the pin-accessible registers are denoted by upper-case names. The registers are generally of
three types:
Data—used for storing data that, in turn, become operands for the functional operators.
Control and status—used for setting different configurations of the machine (control) or indicating the configura-
tion of the machine (status).
Addressing—used for storing information that points to a memory location. In some cases, addressing registers
can be used as general-purpose data registers accessible by data move instructions.
A very important register not directly accessible to the programmer or through external pins is the PC (program
counter register). The machine automatically controls the PC to properly sequence the instructions.
Table 3-1 lists the general set of program-accessible registers sorted by function.
cally and includes their type and location.
gram-accessible registers in a block diagram of the whole chip.

Table 3-1. Program-Accessible Registers by Function

Register Name
r0, r1, r2, r3, j, k, rb, re, ybase
pt, pr, pi, i
p, pl, x, y, yl, a0, a0l, a1, a1l, aa0, aa1
auc, psw
c0, c1, c2
sdx, sdx2
srta, srta2, tdms, tdms2, saddx, saddx2, sioc, sioc2
pdx<0—7> (pdx0 only for DSP1611/18/27/28/29)
phifc (DSP1611/18/27/28/29 only)
pioc (DSP1617 only)
eir, ear, edr (DSP1618/28 only)
pllc (DSP1627/28/29 only)
cbit, sbit
Note: Registers sioc, sioc2, srta, srta2, tdms, and tdms2 are not readable. Alternate accumulators aa0 and aa1 are only acces-
sible with the BMU swap instruction.
