16.2

Warning messages

The various control functions and methods as well as the hardware of the frequency
inverter contain functions that continuously monitor the application. In addition to the
messages documented in the manual, the following warning messages are activated
by the communication module.
The warning messages are given via parameter
the following scheme. The parameter
parameter
VPlus and Keypad KP500.
Bit no. Warning code
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
The meaning of the individual warnings is described in detail in the operating instruc-
tions.
192
269 shows the same information with a short text description in
Warnings
Warning messages
0x0001 Warning Ixt
0x0002 Warning Short Term - Ixt
0x0004 Warning Long Term - Ixt
0x0008 Warning Heat sink Temperature Tc
0x0010 Warning Inside Temperature Ti
0x0020 Warning Limit
0x0040 Warning Init
0x0080 Warning Motor Temperature
0x0100 Warning Mains Failure
0x0200 Warning Motor Protective Switch
0x0400 Warning Fmax
0x0800 Warning Analog Input MFI1A
0x1000 Warning Analog Input A2
0x2000 Warning System bus
0x4000 Warning Udc
0x8000 Warning
CM-EtherCAT
270, bit-coded according to
Warnings
270 is meant to be read out by PLCs,
Warnings
Meaning
Warning status application
367
