15 Parameter list

The parameter list is structured according to the menu branches of the operating unit.
For better clarity, the parameters have been marked with pictograms:
The parameter is available in the four data sets
The parameter value is set by the SET-UP routine
This parameter cannot be written when the frequency inverter is in operation
15.1

Actual values

No.
228 Internal reference frequency
249 Active data set
260 Current error
270 Warnings
274 Application Warnings
282 Reference bus frequency
283 Reference ramp frequency
1443 Node-State (NMT)
1453 OS SyncSource Act
1108 Actual Position
1109 Act. Contouring Error
The parameters
are only accessible via the communication channel of objects PPO1 and PPO2. It can-
not be accessed via the VPlus program or the KP500 control unit.
186
Description
Actual values of the frequency inverter
Actual values of the Motion Control Interface
260
Current error
CM-EtherCAT
Unit Display range
Hz -1000.00 ... 1000.00
-
- 0 ... 0xFFFF
- 0 ... 0xFFFF
- 0 ... 0xFFFF
Hz -1000.00 ... 1000.00
Hz -1000.00 ... 1000.00
-
-
--2147483647 ...
u
2147483647
--2147483647 ...
u
2147483647
,
270 and
Warnings Application Warnings
Chapter
14.3.3
1 ... 4 14
12.5.2
16.4
16.2
16.3
14.3.3
14.3.3
0 ... 127 11.7
Selection 11.8
12.5.14
12.5.41
274
